The Kawasaki Z H2 example identifies R7F701442 and names Peng’s Datarepair Software. Its instrument, connection and software images provide the available application reference; a model year and full instrument part number are not stated.
- Application
- Kawasaki Z H2
- Chip reference
- R7F701442
Instrument and module identification
Programming connections
Software reference screens
Recorded data notes
- Vehicle: Kawasaki Z H2
- Chip Type: R7F701442
- Software Used: Peng’s Datarepair Software
Use the R7F701442 board reference with its instrument
The pictured Z H2 board and its annotated connections are the evidence for this entry. Record the full MCU marking and board revision before selecting the programmer. Other motorcycles using an R7F701442-family device may have different connection points.
